Air Conditioner Units
The RTX 2000 head unit only. Please select one of the installation kits to use with the unit.
Exterior dimensions: 25.4″ long x 33.9″ wide x 6.6″ tall.
Interior dimensions: 13.9″ long x 14.4″ wide x 5.5″ tall.
Shop our Patent Pending AC roof adapters, seal and interior bezel to make the install easier.
The AC unit will not come with internal framing support. We highly recommend getting our framing.
Promaster rtx internal framing
IMPORTANT!! If you are ordering the DIYvan install kit please watch Hein's Video on how to install the inserts.
Compact size leaves more space for solar panels and other things on your van’s roof.
Only uses 19 amps of energy in eco mode – power consumption ranges between 10 amps to 58 amps.
Recommended to be used with a battery bank of 180 amp hours or larger.
Suitable for ambient temperatures between 41 and 126 degrees Fahrenheit.
Includes remote control.
This unit is AC only, there is no “fan only” mode for recirculating air.
One year manufacturer warranty.
The opening size is 15 1/2 by 14 1/8.
DISCLAIMER:
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
Popular, 12 volt rooftop air conditioner from Dometic. Includes Dometic's wiring and hardware kit.
Shop our Patent Pending AC roof adapters to make the install easier.
Typically ships within 5 business days directly from our supplier and can take another 5-7 days to arrive via truck freight.
6,824 BTU.
Exterior dimensions: 25.4″ long x 33.9″ wide x 6.6″ tall.
Interior dimensions: 13.9″ long x 14.4″ wide x 5.5″ tall.
Compact size leaves more space for solar panels and other things on your van’s roof.
Only uses 19 amps of energy in eco mode – power consumption ranges between 10 amps to 58 amps.
Recommended to be used with a battery bank of 180 amp hours or larger.
Suitable for ambient temperatures between 41 and 126 degrees Fahrenheit.
Includes remote control.
This unit is AC only, there is no “fan only” mode for recirculating air.
One year manufacturer warranty.
The opening size is 15 1/2 by 14 1/8.
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
INSTALLATION VIDEO:
Shop our Patent Pending AC roof adapters to make the install easier. Sprinter, Transit, Promaster.
Typically ships within 3-4 business days and can take another 5-7 days to arrive via truck freight.
The Plein-Aircon is an innovative rooftop mounted air conditioning system for RVs and vans. This Indel B rooftop-mounted AC features ground-breaking technology, that makes the air conditioning unit convenient, efficient, powerful, and reliable. The Indel B Plein provides 4100 BTU (1200W) of cooling.
With a built-in power supply, you can use the Plein-Aircon even while stopped, without having to idle the engine. Thanks to the Smart Switch built into the power supply, the Plein can be powered by both 12V DC and 115V AC power.
The cutting-edge 12V Samsung compressor works nearly silently, while using as low as 16 Amps per hour. It reliably cools and dehumidifies the air.
This air conditioning unit comes with multiple comfort features, as well. If you want to schedule the AC to turn on in the morning, or before you go to sleep, you can take advantage of the timer, which lets you schedule ON and OFF times down to the minute. Controlling the Plein-Aircon is made easy and intuitive with the included remote control. Set the temperature, blower speed, and fan mode from anywhere in your cabin.
Technical Specifications of the Indel B Plein-Aircon:
|
Input Voltage |
12V DC (115-230V AC) |
|
Maximum Power |
4100 BTU (1.2 KW) |
|
Power Consumption |
16-42 A/h |
|
Coolant Type |
R134a |
|
Fan Operating Modes |
3 speeds + auto mode |
|
Weight |
55.8 lbs (25.3 kg) |
|
External Dimensions |
9.7 x 26.4 x 31.5 in (246.4 x 670.5 x 800 mm) |
|
Internal Dimensions |
2 x 21 x 23.6 in (50.8 x 533.4 x 600 mm) |
|
Roof cut-out Dimensions |
15.8 x 15.8 in (401 x 401 mm) |
|
Suitable Roof Thickness |
from 1.2 to 2.75 in (30.5-70 mm) |
Disclaimer: Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
