Free shipping on most products in the US. DIYvan is there for every step of our Do It Yourself Van Conversion with experienced advice and our full Impact Products line including 3M Thinsulate, 80/20 cross bars, solar mounting brackets, storage solutions and roof vent adapters. We are dedicated to helping DIY and professional up-fitters with their van projects. It is our pleasure to share our engineering and fabrication knowledge and experience to help you complete your build and enjoy your van in comfort, safety and efficient style.
These fit in the outer rounded positions. They will not work in the inner straight positions, see other listing.Dash Switch adapters for installing rocker switches in VS30 Sprinter dash. (These are not compatible with the NCV3 Sprinter) 3D printed in tough nylon plastic. Use of a relay to carry larger loads is recommended. Not all switches have the same load (Amp) capacity. Refer to drop down list for current ratings.
SPST (single pole single throw) is simple on/off switch (most common)SPDT (single pole double throw) is on/on switch which can also be used as on/off. These can also be used for 2-way control with another SPDT.DPDT and DPST (double pole) are essentially two switches tied together and actuated simultaneously. One side can be used as simple on/off switches (same as SPDT or SPST) or to switch both negative and positive at the same time. Also wired as reversing (polarity reversing) switches.SPDT with center off means the there is a middle position that is not connected to either output Lighted switches means the light comes on when the load is energized. Refer to photos for proper connections. These will need a ground connection for the light to work.
A quantity of one equals one adapter and one switch.
If you have questions about this product you can call Hein at 541-49O-5O98Check out our other items!
Dash Switch adapters for installing rocker switches in 2007 - 2018 NCV3 Sprinter dash locations. 3D printed in tough nylon plastic. We have adapters with SPST and SPDT (center off) switches. Use of a relay to carry the load is recommended. See wiring diagram here: http://www.impact3d.com/relay_wiring.jpg
For the lighted switches; The gold terminal is connected to ground(-). The outer silver terminal is +12V in (battery), The middle silver terminal is the load (light, relay, etc.)
Colors may vary in shade and some have I (on) O (off) markings on them that aren't shown in the photos.
Momentary switches are normally open and make contact when pressed in and held.
A quantity of one equals one adapter and one switch.
If you have questions about this product you can call Hein at 541-49O-5O98
These fit the inner straight positions. They will not work in the outer rounded positions, see other listing.
Dash Switch adapters for installing rocker switches in VS30 Sprinter dash. (These are not compatible with the NCV3 Sprinter) 3D printed in tough nylon plastic. Use of a relay to carry larger loads is recommended. Not all switches have the same load (Amp) capacity. Refer to drop down list for current ratings.
SPST (single pole single throw) is simple on/off switch (most common)
SPDT (single pole double throw) is on/on switch which can also be used as on/off. These can also be used for 2-way control with another SPDT.
DPDT and DPST (double pole) are essentially two switches tied together and actuated simultaneously. One side can be used as simple on/off switches (same as SPDT or SPST) or to switch both negative and positive at the same time. Also wired as reversing (polarity reversing) switches.
SPDT with center off means the there is a middle position that is not connected to either output
Lighted switches means the light comes on when the load is energized. Refer to photos for proper connections. These will need a ground connection for the light to work.
A quantity of one equals one adapter and one switch.
If you have questions about this product you can call Hein at 541-49O-5O98
Low profile solar entry puck. 2, 4 and 6 wire versions available. VHB mounted base and matching cap plate. Comes with rubber grommet to protect wires from edge of hole cut into roof, 4 self drilling screws and sealant for around wires and between base and cap.
- 2 and 4 wire size is 2 1/4 inch x 2 1/4 inch. Drill hole is 1"
- 6 wire size is 3 inch x 3 inch. Drill hole is 1 1/2"
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold ?as is? and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
Dash Switch adapters for installing rocker switches in Ford Transit 2015 to 2019 upper dash. 3D printed in tough nylon plastic. Use of a relay to carry larger loads is recommended. Not all switches have the same load (Amp) capacity. Refer to drop down list for current ratings.
If you have questions about this product you can call Hein at 541-49O-5O98
SPST (single pole single throw) is simple on/off switch (most common)
SPDT (single pole double throw) is on/on switch which can also be used as on/off. These can also be used for 2-way control with another SPDT.
DPDT and DPST (double pole) are essentially two switches tied together and actuated simultaneously. One side can be used as simple on/off switches (same as SPDT or SPST) or to switch both negative and positive at the same time. Also wired as reversing (polarity reversing) switches.
SPDT with center off means the there is a middle position that is not connected to either output
Lighted switches means the light comes on when the load is energized. Refer to photos for proper connections. These will need a ground connection for the light to work.
A quantity of one equals one adapter and one switch.
If you have questions about this product you can call Hein at 541-49O-5O98
These are pre-wired fully assembled breaker boxes for use with shore power systems typically used in vans. Features a 15, 20 or 30A Bluesea A-series 2-pole breaker with power on and reverse polarity LED indicators. Front panel is ABS plastic and box is standard PVC electrical box. Connections to breaker are made with double crimped Ancor terminals. 10ft of 3 conductor stranded SO cord extends from line and load sides for easy wiring into system. Line side should be as short as possible. Connect shore power plug or receptacle to LINE end and AC load panel, transfer switch, inverter, or inverter/charger to LOAD end. Each unit is function tested before shipment. Recommend that SO cord be routed inside conduit or split loom (not included) for added protection. Use edge guard or grommets to protect cord from sharp edges.
Use formula of Watts (max load) divided by Volts to determine Amperage required. Example: 1500W/120V=12.5A (use 15A breaker)
WARNING: Improperly installed or wired shore power system can be an electrocution hazard which can cause serious injury or death. Get assistance from a qualified electrician if unfamiliar with these systems.
If you have questions about this product you can call Hein at 541-49O-5O98
ABS plastic panels for mounting Bluesea A-series toggle breakers in standard 2.38" deep PVC outlet boxes. Mounting screws included.
PLEASE NOTE: Some boxes may not be deep enough to fit the breakers. Search for these items to purchase boxes
single gang: Cantex 5133463
double gang: Cantex 5133371
Double pole version is typically used directly after shore power connection. Panel has two small holes for Bluesea green and red LEDs that indicate power on and reverse polarity. Refer to wiring diagram on how to connect LEDs, load, neutral and ground.
Bluesea red LED 8066
Bluesea green LED 8034
Single pole with outlet version can be used downstream of inverter. Load goes through breaker, with neutral and ground connected to outlet.
Refer to Bluesea wiring diagrams and ABYC electrical standards to insure proper wiring and connections. Consult qualified electrician if unsure how to wire properly. Incorrect wiring can result in electrocution hazard leading to serious injury or death.
This listing is for the panels only. PVC box, breaker, LEDs and outlets are not included.
If you have questions about this product you can call Hein at 541-49O-5O98
Order our prewired shore power breaker box online at https://diyvan.com/products/prewired-shore-power-breaker-box
KISAE Abso DC-DC Charger 50A DMT1250
DC to DC Battery Charger, Microprocessor controlled multi-stage charging algorithms (bulk, absorption, float) for gel, flooded, Lithium and AGM batteries and equalization for flooded batteries, Silent mode for quiet operation, MPPT solar regulator allows you to provide maximum power from solar panels to battery.
Battery temp sensor available.
If you have questions about this product you can call Hein at 541-49O-5O98
Remote Control for KISAE Abso Battery Chargers. Allows user to monitor battery status and perform unit settings remotely.
DMT1250 DC to DC charger listed at: https://www.ebay.com/itm/143309987713
If you have questions about this product you can call Hein at
541-49O-5O98
The Battery
Temperature Sensor (BTS) is designed for the Abso Chargers series Inverter/Charger. The sensor has a 25 foot cable attached
and it mounts to the battery. It measures the temperate, which
automatically adjusts voltage to help ensure full battery temperature
compensated charging.
DMT1250 DC to DC charger listed at: https://www.ebay.com/itm/143309987713
If you have questions about this product you can call Hein at
541-49O-5O98
Dash Switch adapter with 2 mini SPST (on/off) rocker switches or 1 mini SPST (on/off) rocker switch in Ford Transit 2020 to present. Location is small panel just ahead of gear shift. Easily reached by driver or passenger. Made of 3D printed in tough nylon plastic. Use of a relay to carry larger loads over 5 amps DC is recommended.
To install use trim tool to carefully remove bezel around shifter knob. Then pull up and outward on existing plastic panel which will be replaced with this part. Advisable to solder 12" leads to switch terminals as there is limited room for crimp terminals on back of switch. These can interfere when installing the panel preventing it from seating completely. Route wires down and to left and they will drop out below steering column. There is a panel under the dash that can be removed to retrieve wires from below.
Let us do the work for you! Preloaded heated under vehicle battery box for Ford Transit Vans. Fits 130 WB, 148 WB, with or without a diesel fuel system. Spacious heavy duty formed steel box These fit under the chassis on the drivers side.
NOT COMPATIBLE WITH THE ALL WHEEL DRIVE TRANSIT 350 VAN
This battery box will include:
1 painted steel box for 2500
2 batteries
2 battery hold down brackets
1 180 Bluesea waterproof breaker
(mounted to outside of box)
1 negative ground post
(mounted to outside of box)
Cables from batteries to breaker
and negative post. Hydraulically
crimped and routed in split loom
50 watt heat elements under each
battery and wired to digital
controller (you mount in van)
3M Thinsulate AU4002-5 caps for
each battery. Minicell foam
insulation under batteries.
If you have questions you can text Hein 541-490-5098
Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold "as is" and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
Let us do the work for you. Preloaded heated under vehicle battery box for Sprinter NCV3 2500 170WB and 3500 170WB. Spacious heavy duty formed steel box.
This set up will include:
1 powder coated steel box.
2 Batteries, may not be batteries shown in photo
2 battery hold down brackets
1 180 Bluesea waterproof breaker
(mounted to outside of box)
1 negative ground post
(mounted to outside of box)
Cables from batteries to breaker
and negative post. Hydraulically
crimped and routed in split loom
50 watt heat elements under each
battery and wired to digital
controller (you mount in van)
3M Thinsulate AU4002-5 caps for
each battery. Minicell foam
insulation under batteries.
If you have questions about this product you can text Hein at 541-490-5098
Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold ?as is? and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
KISAE Abso SW Inverter Charger 1000W 40A
Run your household appliances in your truck, boat or RV
True Sine Wave output to run motor loads and sensitive electronics
Multi-stage charger will charge your deep cycle batteries quickly and efficiently
Integrated transfer switch allows you to switch seamlessly from shore power to battery power
Ideal inverter for running microwave ovens, kitchen appliances, and consumer electronics
True Sine Wave output to run motor loads and sensitive electronics
Multi-stage charger will charge your deep cycle batteries quickly and efficiently
Integrated transfer switch allows you to switch seamlessly from shore power to battery power
Ideal inverter for running microwave ovens, kitchen appliances, and consumer electronics
If you have questions about this product you can call Hein at
541-49O-5O98
