Favorite Products
- Delivers more acoustic absorption per unit weight vs. competitive products
- Helps customers meet mass reduction goals
- Non-woven sound absorbing fibers create a quieter vehicle environment
- Hydrophobic fibers resist moisture, mold and mildew
Add our Thinsulate Installation kit: scissors, 4ft flexible rod and high strength string. We will ship it inside your roll of Thinsulate.
Recommend using 3M 90 Adhesive Spray to apply the white fiber side to the Van skin.
Approximate amounts needed to insulate the walls, ceiling, doors and cab area:
144 WB Sprinter,148 WB Ford Transit with slider window & window in back doors = 50 linear feet
Promaster 159 WB = 60 linear feet
170 WB Sprinter = 60 linear feet
170 WB Extended Sprinter = 70 linear feet
Any order over 45 linear feet will ship in two rolls.
Please call if you are in Alaska or Hawaii for shipping 541-49O-4292
Hardware to attach these to the panel is included. The towers are available in clear hard anodized and black hard anodized. Some fading may occur due to sun exposure.
DISCLAIMER
Failure to follow warnings below may allow rack to come loose from vehicle and cause injury or death.
Do not exceed 20 lbs load on each tower.
- Do not extend any component more than 4" beyond forward or rearward most towers.
- Do not exceed total allowable load by vehicle manufacturer.
- Use all available attachment points on van roof.
- Do not install roof top deck or climb on rack.
- Check and tighten all hardware after 100 miles and every 500 miles there-after.
- Check overall integrity of rack every 500 miles or monthly whichever is more frequent.
If in doubt, please submit rack plans or photos for evaluation prior to final installation or use.
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
- Delivers more acoustic absorption per unit weight vs. competitive products
- Helps customers meet mass reduction goals
- Non-woven sound absorbing fibers create a quieter vehicle environment
- Hydrophobic fibers resist moisture, mold and mildew
Please call if you are in Alaska or Hawaii for shipping 541-49O-4292
Product is between 4 to 8mm thick, 60" wide.
This is a nice interlining for blankets or window shades. Adding a layer of Thinsulate between your other materials will add warmth.
Recommend using 3M 90 Adhesive Spray to apply to the Van skin.
Tips for insulating: http://impact3d.com/Thinsulate_installation.html
Please call if you are in Alaska or Hawaii for shipping 541-49O-4292
We recommend using 3M 90 Adhesive Spray to apply the white fiber side to the Van skin.
We also sell 3M SM600L which is the thickest grade engineered for vehicles
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
WARNING!! Please verify the opening requirement on your Maxxair Fan. If it is 400mm x 400mm you need to purchase an adapter from our Ford Transit Euro Adapter listing.
Pair with our Insulated Vent Fan Cover and Maxxfan Deluxe 7500K or 7000K Electric Lid Opening
Click here for our custom adapter inquiry form.
Patent Pending adapter matches the contour of the OEM roof so a standard RV style vent mounts to a flat surface. Prevents distorting the roof sheet metal or vent flange and can be used as an aid for locating the fan. They are CNC machined out of UV and fire resistant expanded PVC. The fan mounts to the outside adapter. Fan adapters work with the Maxxfan Deluxe series and the Fan-tastic Vent fans.
The framing strips are expanded PVC and bonded to the roof with a thick bead of Windoweld. They are more flexible than wood and plenty strong to support the vent and keep it from jiggling. We double them up when installing roof top air conditioners. They are essential if the span between the OEM roof beams is more than 18". They also provide a backing for the screws that hold up the vent interior bezel. They should be placed 1/4" away from the edge of the hole so the screws for the vent go into the strips. They are a generic size and will need to be cut to length. These strips are not contoured to the van corrugations.
Fits a 14" x 14" opening. Photo of the adapter is in the offset position.
The vent adapter outside dimension is 16 3/4 X 16 3/4. If you are using a Maxxair vent our adapter fits the Maxxfan Deluxe series, other Maxxair vents have a wider flange. You will need a wider adapter. Please call.
If the butyl tape is stuck to the plastic, put it in the freezer for 30 minutes. It will release, then let the butyl tape return to room temperature.
Longer screws than came with the vent fan may be needed.
Roof Vent Adapter Install procedure:
We recommend 3m Window-weld or Sikaflex 221 adhesive. Locate and cut the 14 x 14 hole. You can use the adapter as a guide to mark the hole. Stay clear of roof supports, obviously. Make a tape line 1/4" beyond the adapter perimeter. De-gloss the area with a Scotch- brite pad. No need to scuff. Just dull the paint. Clean with isopropyl alcohol and let dry thoroughly. Blow dryer if it's wet and/or cold out. Apply three 1/8" beads of the Window-weld on the face of the adapter. Then press the adapter down onto the roof until the adhesive oozes out the sides. It's not necessary to clamp. If you do, use a lot of lightly set clamps and spread out the clamp force over the whole surface area. Using the adhesive that oozes out, make a fillet around the adapter with a double gloved finger. Pull the tape within 15 minutes. Cure is fast on outside. Let cure overnight and then proceed with the fan install. We recommend using butyl tape for the fan install. Cover the fan flange with 1 1/8" wide tape. Place onto of adapter and press down. Then drill pilot holes through the adapter and into the van roof. If the screws are going to go into a roof support beam then drill a clearance hole in the beam. You only want the screw to engage the adapter and outer skin. Use a step drill to keep from plunging through the skin. You may need longer screws. Tighten them very lightly against the fan flange. Some butyl will ooze out which you can trim off. Seal the adapter and onto the roof about 1/2" with Dicor self leveling sealant or Flexseal from the TV guy works well. Good idea to check the integrity and reapply the sealant every so often.
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
WARNING!! Please verify the opening requirement on your Maxxair Fan. If it is 400mm x 400mm you need to purchase an adapter from our Ford Transit Euro Adapter listing.
Pair with our Insulated Vent Fan Cover and Maxxfan Deluxe 7500K or 7000K Electric Lid Opening
Patent Pending adapter matches the contour of the OEM roof so a standard RV style vent mounts to a flat surface. Prevents distorting the roof sheet metal or vent flange and can be used as an aid for locating the fan. They are CNC machined out of UV and fire resistant expanded PVC. The fan mounts to the outside adapter. Fan adapters work with the Maxxfan Deluxe series and the Fan-tastic Vent fans.
Please see our Interior support strips: https://diy-van.myshopify.com/admin/products/5783792779421
IMPORTANT
Fan adapters work with the Maxxfan Deluxe series and the Fan-tastic Vent fans.
The outside adapter will fit anywhere along the cargo part of the roof. Longer screws than came with the vent fan may be needed.
The vent adapter outside dimension is 16 3/4 X 16 3/4. If you are using a Maxxfan vent our adapter fits the deluxe series, other Maxxfan vents have a wider flange. You will need a wider adapter. Please text Hein at 541-490-5098 for help.
If you order the framing strips they will come in a separate box.
The option with butyl tape includes 64" of tape.
We make adapters to fit air conditioners and adapters for offset locations. Please contact us so we can verify size and location.
The Low Roof Vent Adapter will also fit on the forward position on the Mid Roof Transit.
Roof Vent Adapter Install procedure: We recommend 3M Window-weld or Sikaflex 221 adhesive for adhering the adapter to the roof. Locate and cut the 14 x 14 hole. You can use the adapter as a guide to mark the hole. Stay clear of roof supports, obviously. Make a tape line 1/4" beyond the adapter perimeter. De-gloss the area with a Scotch- brite pad. No need to scuff. Just dull the paint. Clean with isopropyl alcohol and let dry thoroughly. Blow dryer if it's wet and/or cold out. Apply three 1/8" beads of the Window-weld on the face of the adapter. Then press the adapter down onto the roof until the adhesive oozes out the sides. It's not necessary to clamp. If you do, use a lot of lightly set clamps and spread out the clamp force over the whole surface area. Using the adhesive that oozes out, make a fillet around the adapter with a double gloved finger. Pull the tape within 15 minutes. Cure is fast on outside. Let cure overnight and then proceed with the fan install. We recommend using butyl tape for the fan install. Cover the fan flange with 1 1/8" wide tape. Place onto of adapter and press down. Then drill pilot holes through the adapter and into the van roof. If the screws are going to go into a roof support beam then drill a clearance hole in the beam. You only want the screw to engage the adapter and outer skin. Use a step drill to keep from plunging through the skin. You may need longer screws. Tighten them very lightly against the fan flange. Some butyl will ooze out which you can trim off. Coat the fan flange adapter and onto the roof about 1/2" with brush on bed-liner or Flexseal from the TV guy works well. Some sealants will melt the fan plastic so you might try it on a portion of the interior bezel first. You'll cut a lot of that piece off. Good idea to check the integrity and reapply the sealant every so often. Dicor self leveling sealant also works but looks a little messy.
If you have questions about this product you can call Hein at 541-49O-5O98
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
Patent Pending. Sold in pairs. Ford Transit tower brackets. Laser cut, CNC formed tower brackets for use with 15 series 8020 square crossbars to mount solar panels and other accessories to the roof of Ford Transit vans using factory supplied OEM mounting locations. Crossbars are NOT included.
Available with clear or black anodized finish. Towers have EDPM pads to protect paint on roof of van and help seal against moisture. Includes hardware required to mount to van and attach 8020 crossbars. 80/20 bars are NOT included. Order crossbars 55.25" long and tapped 5/16-18 in both ends. Please visit 8020.net to spec and order crossbars. Please contact us for assistance.
*Black Anodizing may fade over time due to sun exposure.
Do not exceed 20 lbs load per tower. Not intended as a rack for hauling large or heavy items. Do not exceed total roof top weight allowed by vehicle manufacturer. Please contact us with any questions about how to use this product.
select 'square' for use with 15 series 8020 square profiles (uses 55.25" crossbars)
select 'rounded' for use with 1517 8020 rounded profile (uses 55.25" crossbars)
select 'extended' if the crossbar needs to extend beyond the tower. Compatible with both rounded and square 8020 profiles. This version does not cap the end of the crossbar so separate caps can be purchased with the 8020. Maximum extension beyond tower not to exceed 6". Not suitable for mounting heavy awnings not otherwise supported.
Please take a look at our support tabs for mounting solar panels to the cross bars, item number
141878685652. We also have a listing for 8020 cross bars, item number 132871157220.
If you have questions about this product you can call Hein at 541-49O-5O98
WARNING!
Failure to follow warnings below may allow rack to come loose from vehicle and cause injury or death.
- Do not exceed 20 lbs load on each tower.
- Do not extend any component more than 4" beyond forward or rearward most towers.
- Do not exceed total allowable load by vehicle manufacturer.
- Use all available attachment points on van roof.
- Do not install roof top deck or climb on rack.
- Check and tighten all hardware after 100 miles and every 500 miles there-after.
- Check overall integrity of rack every 500 miles or monthly whichever is more frequent.
If in doubt, please submit rack plans or photos for evaluation prior to final installation or use.
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
Click here for our custom adapter inquiry form.
Please check your fan opening size requirement!!
Patent Pending adapter matches the contour of the OEM roof so a standard RV style vent mounts to a flat surface. Prevents distorting the roof sheet metal or vent flange and can be used as an aid for locating the fan. They are CNC machined out of UV and fire resistant expanded PVC. The fan mounts to the outside adapter. Fan adapters work with the Maxxfan Deluxe series.
Fits a 400mm X 400mm opening. These fans are usually purchased in the UK. If your fan requires 14" x 14" opening please message us.
The outside adapter will fit anywhere along the center of the cargo part of the roof. Please note, if you are installing your fan towards the front of the van on the raised portion, you will not need this adapter.
The option with butyl tape includes 64" of tape. If the butyl tape is stuck to the plastic, put it in the freezer for 30 minutes. It will release, then let the butyl tape return to room temperature.
Roof Vent Adapter Install procedure: We recommend 3m Window-weld or Sikaflex 221 adhesive. Locate and cut the 14 x 14 hole. You can use the adapter as a guide to mark the hole. Stay clear of roof supports, obviously. Make a tape line 1/4" beyond the adapter perimeter. De-gloss the area with a Scotch- brite pad. No need to scuff. Just dull the paint. Clean with isopropyl alcohol and let dry thoroughly. Blow dryer if it's wet and/or cold out. Apply three 1/8" beads of the Window-weld on the face of the adapter. Then press the adapter down onto the roof until the adhesive oozes out the sides. It's not necessary to clamp. If you do, use a lot of lightly set clamps and spread out the clamp force over the whole surface area. Using the adhesive that oozes out, make a fillet around the adapter with a double gloved finger. Pull the tape within 15 minutes. Cure is fast on outside. Let cure overnight and then proceed with the fan install. We recommend using butyl tape for the fan install. Cover the fan flange with 1 1/8" wide tape. Place onto of adapter and press down. Then drill pilot holes through the adapter and into the van roof. If the screws are going to go into a roof support beam then drill a clearance hole in the beam. You only want the screw to engage the adapter and outer skin. Use a step drill to keep from plunging through the skin. You may need longer screws. Tighten them very lightly against the fan flange. Some butyl will ooze out which you can trim off. Coat the fan flange adapter and onto the roof about 1/2" with Dicor self leveling sealant or brush on bed-liner or Flexseal from the TV guy works well. Some sealants will melt the fan plastic so you might try it on a portion of the interior bezel first. You'll cut a lot of that piece off. Good idea to check the integrity and reapply the sealant every so often.
If you have questions about this product you can call Hein at 541-49O-5O98
Van owner and/or installer assumes all risk associated with roof top mounted items and/or components. Van owner and/or installer recognizes and agrees that this product, and each of its component parts, is sold “as is” and that seller makes no representation or warranty of merchantability that the product is fit for any particular purpose.
