Specifications
| Maximum Power ( Pmax): | 100W |
| Maximum Power Voltage (Vmp): | 18.6V |
| Maximum Power Current (Imp): | 5.38A |
| Open Circuit Voltage (Voc): | 22.8V |
| Short Circuit Current (Isc): | 5.78A |
| Maximum System Voltage (Vmax): | 1000VDC |
| Temperature Range: | -40°F~ +185°F |
| Weight: | 13.2 lb |
| Dimensions: | 39.0 × 21.3 × 1.2 in |
ELECTRICAL DATA (STC)
Peak Power Watts-PMAX (Wp)
100 W
Power Output Tolerance
±5%
Maximum Power Voltage-VMPP (V)
18.6 V
Maximum Power Current-IMPP (A)
5.38 A
Open Circuit Voltage-VOC (V)
22.8 V
Short Circuit Current-ISC (A)
5.78 A
Maximum System Voltage
1000 VDC
Temperature Range
-40~+185°F
39.0″
Maximum Series Fuse Rating
10 A
Module Efficiency η m (%)
18.1 %
STC: Irradiance 1000 W/m², Cell Temperature 25 °C, Air Mass AM = 1.5
DISCLAIMER: Owner and/or installer assumes all risks associated with products and/or components purchased from DIYvan. Owner and/or installer recognizes and agrees that this product, and any of its component parts, is sold “as is” and that DIYvan makes no representation or warranty of merchantability that the product is fit for any particular purpose.
